H211d: derailleur gear hanger, same as Focus KD325914004 KD325920084 Pilo D578, dropout for bike frames

H211d Alloy Rear Derailleur Hanger for Focus, Kalkhoff, Raleigh, Univega bikes. Assembly from outside with 2 screws, threading in hanger. Screw Fitting Holes Centre to Centre 20mm Approx, please do not mistake for the nearly identical H212 Hanger Focus #KD325914001 which has a wider c to c (22mm)

Compatible with models of following brands (not exhaustive):

• Focus
  Focus Aventura
  Focus Aventura 1.0 30G
  Focus Aventura 1.0 30G for women
  Focus Aventura 3.0 27G
  Focus Aventura 3.0 27G for women
  Focus Aventura TS 1.0 20G
  Focus Aventura TS 2.0 30G
  Focus Aventura TS 2.0 30G for women
  Focus Bold Pro 2017
  Focus Create Lake
  Focus Create Lake CS1.0 30G
  Focus Create Lake CS1.0 30G for women
  Focus Create Lake CS2.0 30G
  Focus Create Lake CS2.0 30G for women
  Focus Dark Forest 2019
  Focus Whistler ellite 29' 2016 2017 2018

• Kalkhoff
  Kalkhoff Endeavour
  Kalkhoff Track 1.0 cross series

• Raleigh
  Raleigh Rushhour 3.0

• Univega
  Univega Terreno 5.0 2016-2019

Number of fasteners: 2
Screw Fitting Holes Centre to Centre 20mm Approx
Attaches to frame with (2) M4x8 Flat Head Screws
Sold without screws
Mounting on frame:     Outer
Axle diameter:     10mm (Standard QR)
Material:      CNC machined aviation aluminium
Color:  Silver
Derailleur mount type:     Standard mount

Equivalent To:
Focus KD325914004 ,  KD325920084
Pilo D578
Derailleur Hanger #
Marwi GH-266
