H503: derailleur gear hanger, gear dropout hanger, dropout for bikes, replacement hanger Merida DH-053, similar Pilo D545

H503 Rear Derailleur Hanger for various MERIDA frame models. Assembly from inside with 2 screws, threading in hanger.

Compatible with models of following brands (not exhaustive):

• Merida 2021
  BIG.SEVEN/NINE LITE
  BIG.SEVEN/NINE CF3
  BIG.SEVEN/NINE CF5
  NINETY-SIX LITE
  NINETY-SIX CFA
  NINETY-SIX CF4
  NINETY-SIX CF5
  ONE.TWENTY LITE
  ONE.TWENTY CFA
  ONE.TWENTY CF4
  ONE.FORTY LITE
  ONE-SIXTY LITE
  ONE-SIXTY CFA
• Merida 2020
  NINETY.SIX 9. 3000
  NINETY.SIX 9. 400
  ONE.TWENTY RC 9.9000
  ONE.TWENTY RC 9. XT-EDITION
  ONE.TWENTY RC 9.300
  ONE.TWENTY 9.8000
  ONE.TWENTY 9.7000
  ONE.TWENTY 9.3000
  ONE.TWENTY 9.700
  ONE.TWENTY 9.600
  ONE.TWENTY 9.400
  ONE.TWENTY 7.600
  ONE.TWENTY 7.400
  ONE.SIXTY 3000
  ONE.SIXTY 7000
  ONE-SIXTY 700
  ONE.SIXTY 400
  NINETY.SIX 9. TEAM 2300010886
  NINETY.SIX 9. XT (2PCS)
  BIG.NINE 9000
  BIG.NINE 8000
  BIG.NINE TEAM-KR
  BIG.NINE 8900
  BIG.NINE 7000
  BIG.NINE 6000
  BIG.NINE 5000
  BIG.NINE 5000
  BIG.NINE 4000
  BIG.NINE 3000
  BIG NINE XT
  BIG.NINE LTD CF
  BIG.NINE NX-EDITION
  BIG.NINE Limited AL
  BIG.NINE 700
  ONE.FORTY 900
  ONE.FORTY 800
  ONE.FORTY 700
  ONE.FORTY 600
  ONE.FORTY 400
• Merida 2019
  BIG.NINE TEAM / 9000 / 8000-E / 8000 / 7000-E / 7000 / 6000 / XT / 5000 / 4000 / 3000 / 700 / NX-EDITION / LIMITED
  BIG.SEVEN TEAM / 9000 / 8000 / 7000-E / 7000 / 6000 / XT / 5000 / 4000 / 3000 / LIMITED
  ONE.FORTY 900 / 800 / 700 / 600 / 400
  NINETY.SIX 9. TEAM / 9.7000
• Merida 2018
  ONE.SIXTY 8000 / 800
  ONE.FORTY 800 / 700
  ONE.TWENTY 6000 / XT-EDITION
  NINTEY.SIX XT
  BIG.NINE TEAM / 9000 / 7000-E / XT / 6000 / 4000 / LIMITED / 700
  BIG.SEVEN XT


• This hanger will not fit the Big Seven carbon models


Number of fasteners: 2

Attaches to frame with (2) M3x15 Socket Head Screws
Mounting on frame:     Inner
Material:     Alloy
Axle diameter:     12mm (Through axle)
Color: Black
Derailleur mount type:     Standard mount


Equivalent To:
Merida DH-053
Merida Aka # No.53
Merida MUK 33
Merida Art.-Nr.: 70197 (с резьбой)
Merida Item.No.: 2311004928
Pilo D545
Derailleur Hanger # 450
Marwi GH-
